Elemyo | Updated on 20 October 2025
EMG Analysis Software
MYOstack GUI
MYOstack GUI
MYOstack GUI is powerful and easy to use, free, open-source, cross-platform Python-based graphical interface for EMG analysis using MYOstack sensors. MYOstack GUI provides real-time visualization, analysis, recording and processing of EMG and ECG signals.
Supported operating systems: Windows, Linux, macOS.
The program is distributed free of charge under a MIT license.
Latest version: MYOstack GUI v1.2.0
Supported operating systems: Windows, Linux, macOS.
The program is distributed free of charge under a MIT license.
Latest version: MYOstack GUI v1.2.0
EMG Analyses features
- In-depth EMG signal analysis.
- Real-time display of raw, smoothed, and integrated signals from up to 9 MYOstack sensors.
- Real-time FFT analysys of EMG signals.
- Band-pass and 50/60 Hz notch filters.
- Record and playback up to 9 synchronized EMG channels (in BIN format).
- Supports EMG signals recording in ASCII (.txt) format for compatibility with external analysis software.
The MYOstack GUI interface
- Control panel with EMG signals analysis functions, filtering and recording
- 1 - 9 graphs with EMG data: raw, smoothed, and integrated
- FFT graph with selectable EMG signal channel
- Graph with a diagrams of the current EMG amplitude for each sensor
Fig. 1: Real-time raw, integrated and smoothed EMG signals from 9 MYOstack sensors.
MYOstack GUI installing
Installing on Windows (15 min)
1. Install the "Python 3.12": Download the "Windows installer" on the official Python website: www.python.org/downloads/release/python-3129/ (file located at the bottom of the page) and run it. Then check «Add Python 3.12 to PATH» and click «Install Now».
2. Open the Python IDLE: «Start -> Python 3.12 -> IDLE», or «Start -> search «IDLE»», or in folder C:\Users\%USERNAME%\AppData\Local\Programs\ Python\Python312\Lib\idlelib\idle.py
3. Download MYOstack GUI folder by link https://github.com/ELEMYO/MYOSTACK-GUI. To download, click on the "Code" menu (green) and select "Download ZIP". Then unzip the folder.
4. Run MYOstack GUI. In Python IDLE open "MYOstack_GUI.py" file from downloaded folder: File -> Open -><...>->MYOstack_GUI.py. Then click F5, or Run -> Run module. The program will start.
Please Note: At the first start, an Internet connection is required - the program will download and install the missing components (pyserial, pyqtgraph, qtpy5, numpy, scipy modules), this will take some time (5 minutes). Next launches will be quick.
1. Install the "Python 3.12": Download the "Windows installer" on the official Python website: www.python.org/downloads/release/python-3129/ (file located at the bottom of the page) and run it. Then check «Add Python 3.12 to PATH» and click «Install Now».
2. Open the Python IDLE: «Start -> Python 3.12 -> IDLE», or «Start -> search «IDLE»», or in folder C:\Users\%USERNAME%\AppData\Local\Programs\ Python\Python312\Lib\idlelib\idle.py
3. Download MYOstack GUI folder by link https://github.com/ELEMYO/MYOSTACK-GUI. To download, click on the "Code" menu (green) and select "Download ZIP". Then unzip the folder.
4. Run MYOstack GUI. In Python IDLE open "MYOstack_GUI.py" file from downloaded folder: File -> Open -><...>->MYOstack_GUI.py. Then click F5, or Run -> Run module. The program will start.
Please Note: At the first start, an Internet connection is required - the program will download and install the missing components (pyserial, pyqtgraph, qtpy5, numpy, scipy modules), this will take some time (5 minutes). Next launches will be quick.
Installing on macOS (15 min)
1. Install the "Python 3.12": Download the "macOS 64-bit universal2 installer" on the official Python website: www.python.org/downloads/release/python-3129/ (file located at the bottom of the page) and run it.
2. Open the Python IDLE: «Applications -> Python 3.12 -> IDLE»
3. Download MYOstack GUI folder by link https://github.com/ELEMYO/MYOSTACK-GUI. To download, click on the "Code" menu (green) and select "Download ZIP". Then unzip the folder.
4. Run MYOstack GUI. In Python IDLE open "MYOstack_GUI.py" file from downloaded folder: File -> Open -><...>->MYOstack_GUI.py. Then click F5, or Run -> Run module. The program will start.
Please Note: At the first start, an Internet connection is required - the program will download and install the missing components (pyserial, pyqtgraph, qtpy5, numpy, scipy modules), this will take some time (5 minutes). Next launches will be quick.
1. Install the "Python 3.12": Download the "macOS 64-bit universal2 installer" on the official Python website: www.python.org/downloads/release/python-3129/ (file located at the bottom of the page) and run it.
2. Open the Python IDLE: «Applications -> Python 3.12 -> IDLE»
3. Download MYOstack GUI folder by link https://github.com/ELEMYO/MYOSTACK-GUI. To download, click on the "Code" menu (green) and select "Download ZIP". Then unzip the folder.
4. Run MYOstack GUI. In Python IDLE open "MYOstack_GUI.py" file from downloaded folder: File -> Open -><...>->MYOstack_GUI.py. Then click F5, or Run -> Run module. The program will start.
Please Note: At the first start, an Internet connection is required - the program will download and install the missing components (pyserial, pyqtgraph, qtpy5, numpy, scipy modules), this will take some time (5 minutes). Next launches will be quick.
Installing on Linux (10 min)
1. Install the "Python 3.12". Check if Python is preinstalled https://docs.python.org/3/using/unix.html.
If not installed, install according to instructions: https://docs.python.org/3/using/unix.html.
2. Download MYOstack GUI folder by link https://github.com/ELEMYO/MYOSTACK-GUI. To download, click on the "Code" menu (green) and select "Download ZIP". Then unzip the folder.
3. Run MYOstack GUI. In the terminal go to the folder with the MYOstack_GUI.py file and run the command: python3 MYOstack_GUI.py
Please Note: At the first start, an Internet connection is required - the program will download and install the missing components (pyserial, pyqtgraph, qtpy5, numpy, scipy modules), this will take some time (5 minutes). Next launches will be quick.
1. Install the "Python 3.12". Check if Python is preinstalled https://docs.python.org/3/using/unix.html.
If not installed, install according to instructions: https://docs.python.org/3/using/unix.html.
2. Download MYOstack GUI folder by link https://github.com/ELEMYO/MYOSTACK-GUI. To download, click on the "Code" menu (green) and select "Download ZIP". Then unzip the folder.
3. Run MYOstack GUI. In the terminal go to the folder with the MYOstack_GUI.py file and run the command: python3 MYOstack_GUI.py
Please Note: At the first start, an Internet connection is required - the program will download and install the missing components (pyserial, pyqtgraph, qtpy5, numpy, scipy modules), this will take some time (5 minutes). Next launches will be quick.
